The SICK KT5W-2P1116 is a compact industrial contrast sensor designed for fast, reliable detection of differences in contrast on moving materials and machine processes. It is part of SICK’s KT5 family and uses an RGB LED light source to evaluate contrast differences between a target mark and its surrounding background.
This model is commonly suited to applications involving print-mark detection, registration control, positioning, labeling, packaging, cutting, and other automated processes where the machine must recognize a defined contrast change quickly and consistently.
Product Details
• Manufacturer: SICK
• Model: KT5W-2P1116
• Manufacturer Part Number: 1018044
• Product Type: Contrast Sensor
• Product Family: KT5
• Housing Design: Rectangular
• Dimensions: 30.4 mm × 53 mm × 80 mm
• Sensing Distance: ≤ 10 mm
• Light Source: RGB LED
• Wavelengths: 470 nm, 525 nm, and 640 nm
• Light Spot Size: 1.2 mm × 4.2 mm
• Light Spot Direction: Vertical
• Adjustment Method: Teach-in button
• Teach-in Mode: Static 2-point teach-in
• Supply Voltage: 10–30 V DC
• Current Consumption: < 80 mA without load
• Switching Frequency: 10 kHz
• Response Time: 50 µs
Need this exact part? Send Corwin Solutions your required quantity, condition and delivery deadline for a sourcing quote. Availability is confirmed when quoted; compatible alternatives require application-specific verification.
